| Case Specification |
| Dimensions |
463 x 220 x 486 mm (DWH) |
| Form Factor |
Mid Tower |
| Materials |
Steel + Plastic |
| Mainboard Support |
ATX, M-ATX, ITX |
| Front Access & Controls |
Power, LED Control Button, 2 x USB3.0, HD-AUDIO |
| Side Panel |
4 mm Tempered Glass Side Panel |
|
| Expansion & Drive Bays |
| Expansion Slots |
7 |
| 5.25" |
1 |
| 3.5" /2.5" |
3/2 |
| 2.5" |
3 |
|
| Fan |
| Front |
3 x 120mm/2 x 140mm |
| Top |
3 x 120mm / 2 x 140mm (w/o ODD and w/o ODD bracket)
2 x 120mm / 2 x 140mm (w/o ODD but with ODD bracket)
2 x 120mm / 1 x 140mm(When ODD is installed) |
| Power Supply Shroud |
2 x 120mm |
| Rear |
1 x 120mm |
| Pre-installed Fans |
3 x 120mm ARGB fans in front
1 x 120mm fan (Reverse Fan) on PSU shroud
& 1 x 120mm fan in rear |
|
| Radiator Support |
| Front |
120/240/280/360mm (≤ 55mm thickness when fans are installed outside of front panel)
(≤ 30mm thickness when fans are installed inside of front panel)
[Max Radiator Length ≤ 405mm] |
| Top |
240/280/360mm (w/o ODD and w/o ODD bracket)
240/280mm (w/o ODD but with ODD bracket)
120mm(When ODD is installed)
[Max Radiator Length ≤ 405mm] |
| Rear |
120mm |
|
| Clearance |
| Max GPU Length |
≤ 405mm |
| Max CPU Cooler Height |
≤ 175mm |
| Max PSU Length |
≤ 205mm |
|
| Miscellaneous |
| Dust Filter |
Front / Top / Bottom / Right Hand Side |
| Net Weight |
7.55KG |
| Gross Weight |
8.7KG |
| Warranty |
2 years |
| UPC# |
0-761345-80050-1 |
|
